Chain
Rear chain adjustment
• Undo M10 bolt with 8mm Allen key and 17mm spanner until eccentric is just loose.
• Rotate eccentric idler anticlockwise until longest chain run (bottom) has 5mm up and down free.
• Tighten 17mm nut to 43Ftlbs\ 58Nm and check chain free play again.
