EAW AX366 - Enclosure Details

Eastern Acoustic Works One Main Street Whitinsville, MA01588 tel 800 992 5013 / 508 234 6158 fax 508 234 8251 www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. Part Number: RD0187 (B) AX366 April 2005
AX366 Specifications group · I
ENCLOSURE
Material Baltic birch plywood
Finish Wear resistant textured black paint
Grille Powder-coated perforated steel
B
DIMENSIONS APPLY TO BOTH SIDES
40°
0010425-96
(23.98)
RIGHT SIDE
VIEW B-B
[609.0]
2.12
20.00
36.00
FRONT
GRILLE PARTIALLY SHOWN
[914.4]
32.06
[814.3]
C
L
9.76
[247.9]
2.13
3.48
40°
20.32
[609.6]
24.00
[516.1]
TOP
DIMENSIONS APPLY
TO TOP AND BOTTOM
[88.5]
[54.1]
[304.2]
(11.98)
L
C
A
15.79
3.48
B
A
[401.0]
[53.8]
[88.5]
[508.0]
C
L
8.65
15.79
4.00
5.00
VIEW A-A
PRODUCTION
L
C
[127.0]
[101.6]
EA STERN ACO USTIC WORKS
BACK
SERIAL NUMBER
INPUT
20.65
L
C
PLATE
[524.5]
NOTES
1. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE).
2. SYMBOL INDICATES CENTER OF BALANCE. 3. WEIGHT APPROX. 124 lb [56.2 kg] 4. SHIPPING WEIGHT APPROX. 144 lb [65.3 kg]
CABINET/FINISHED/BLACK/AX344 CABINET/FINISHED/BLACK/AX366
CABINET/FINISHED/BLACK/AX396
CABINET/FINISHED/BLACK/AX364
DESCRIPTION
[401.0]
0010425-66 0010425-64
DRAWING NO.
0010425-44
AX3
[219.7]
L
C
NOTES: This drawing has been reduced. Do not scale.
For WP version, add 0.25 in / 6.4 mm to the outside dimensions = 0.125 in / 3.2 mm all around.
