34 – DX8
Appendix B: Logic Output Functions
Logic Output
Function Parameter Condition
Inactive None None
Inp Sig Present Input 1-8 Input Signal > –40 dB
Out Sig Present Output A Output A Signal > –40 dB
Output B Output B Signal > –40 dB
Input Chan Open Input 1-8 Input Gain > –40 dB
Output Chan Open Output A Output A Signal > –40 dB
Output B Output B Signal > –40 dB
Preset Active Preset 1-16 Preset Active
Priority Inactive None No priority input forced on
Auto-gate Status Input 1A-8A LED on if gate active
Input 1B-8B LED on if gate active
Appendix A: Logic Input Functions
Logic Input
Function Action Affected I/O
Inactive None None
Force-On Momentary Input 1 to Input 8
None Input 1 to Input 8
Force-Off Momentary Input 1 to Input 8
None Input 1 to Input 8
Mute Input Momentary Input 1 to Input 8
Latch On Input 1 to Input 8
Latch Off Input 1 to Input 8
Toggling Input 1 to Input 8
Mute Output Momentary Output A
Output B
Output A&B
Latch On Output A
Output B
Output A&B
Latch Off Output A
Output B
Output A&B
Toggling Output A
Output B
Output A&B
Mute Group Momentary Mute Group 1 to Mute Group 8
Latch On Mute Group 1 to Mute Group 8
Latch Off Mute Group 1 to Mute Group 8
Toggling Mute Group 1 to Mute Group 8
Preset Recall Momentary Preset 1 to Preset 16
Latch On Preset 1 to Preset 16
