SB1000zP Specifications group · M
ENCLOSURE
Material Baltic birch plywood
Finish Wear resistant textured black paint
Grille Powder-coated perforated steel
[603.2]
23.75
DIMENSIONS APPLY
TO BOTH SIDES
RIGHT SIDE
[46.8]
6.38
26.13
(1.84)
42.00
[603.3]
23.75
[444.5]
L
C
17.50
TOP/BOTTOM
[1033.8]
[161.9]
[260.4]
NOTES:
1. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE).
2. SYMBOL INDICATES CENTER OF BALNCE.
3. WEIGHT APPROX. 162 lbs. [73.5 kgs]
4. SHIPPING WEIGHT APPROX. 189 lbs [85.7 kgs]
GRILLE PARTIALLY SHOWN
10.25
21.00
[757.2]
C
L
[663.7]
29.81
FRONT
[533.4]
[49.5]
[434.3]
17.10
[161.9]
(1.95)
6.38
SB1000zP
PRODUCTION
EA STERN A C O USTIC W ORKS
BACK
11.00
INPUT
L
C
L
C
[107.9]
[279.4]
4.25
C
L
NOTES: This drawing has been reduced. Do not scale.
For WP version, add 0.25 in / 6.4 mm to the outside dimensions = 0.125 in / 3.2 mm all around.
