EAW SB750zF - Enclosure and Physical Dimensions; Enclosure Construction; Dimensional Drawings and Notes

Eastern Acoustic Works One Main Street Whitinsville, MA 01588 tel 800 992 5013 / 508 234 6158 fax 508 234 8251 www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. Part Number: RD0233 (B) SB750zF January 2006
SB750zF Specifications group · S
ENCLOSURE
Material Baltic birch plywood
Finish Wear resistant textured black paint
Grille Powder-coated perforated steel
BACK
INPUT
FRONT
GRILLE PARTIALLY SHOWN
4X HANDLE
34.53
PRODUCTION
VIEW A-A
DIMENSIONS APPLY
TO BOTH SIDES
34.00
[863.6]
OPENING
BOTTOM ONLY
30°
[219.0]
TOP/BOTTOM
(8.62)
A
4.25
9.72
9.50
[241.3]
[246.8]
A
13.00
CASTER PALLET
[330.2]
C
L
[107.9]
SB750zF
EA STERN A C O USTIC W ORKS
[877.2]
25.81
23.38
2X 6.37
[655.6]
[90.5]
3.56
27.00
2X 23.88
[685.8]
C
L
47.00
2X 39.00
[2X 990.6]
[1193.8]
5
C
L
[2X 606.4]
5
2X 10.75
2X 13.09
[2X 273.1]
[2X 332.6]
NOTES:
1. SYMBOL INDICATES 4.00 [101.6] X 1.35 [34.3]
FLY TRACK.
2. SYMBOL INDICATES CENTER OF BALANCE.
3. WEIGHT APPROX. 193 lb [87.5 kg]
4. SHIPPING WEIGHT APPROX. 202 lb [91.6 kg]
5. DIMENSIONS ARE TO CENTER OF FLY TRACK.
[2X 161.9]
5.76
2X 39.00
4.00
[2X 990.6]
[101.6]
5
[593.9]
5
C
L
5
[146.4]
NOTE: This drawing has been reduced. Do not scale.
