EAW subwoofer DC1 - Dimensional Drawing; Input Panels; Physical Details; Weights

SPECIFICATIONS DC1
DIMENSIONAL DRAWING
INPUT PANELS
One Main Street, Whitinsville, MA 01588 508 234 6158 Toll Free 800 992 5013 FAX 508 234 8251 info@eaw.com www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. DC1/2 pp October 2001 Printed in USA
Weights pounds kilograms
Net Weight 401 178
Shipping Weight 442 201
INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE).
INDICATES MOUNTING POINT
3/8-16 THREADED HOLE (NUT PLATE).
INDICATES MOUNTING POINT,
1/4-20 THREADED HOLE (OMNI MOUNT).
FRONT
RIGHT
GRILL
PARTIALLY
SHOWN
LEFT
40.00
DC1 LFDC1 MH
69.68
DC1 LF
BACK
L
C
ACCESS PANEL
1.97
24.22
7.53
L
C
SEE DETAIL
6.32
6.75
7.12
(BOTTOM ONLY)
15.90
20.48
17.20
BOTTOM
TOP
23.28
11.91
INPUTS
(TOP ONLY)
5.00
12.16
SIDES
8.50
36.10
6.37
1.95
Manufacturing tolerances are +/- 0.13 and +/- 1°
PHYSICAL continued
69.7
DC1 LF
WHITINSVILLE, MA USA
S/N
NEUTRIK
NL 4 MPR
NEUTRIK
NEUTRIK
NL 4 MPR
NEUTRIK
DC1 LF
PIN 1--...--
PIN 1+...+
DC1 MH
WHITINSVILLE, MA USA
S/N
PIN 1--...LF LEFT--
INPUTS
OUTPUTS
PIN 1+...LF LEFT+
PIN 1--...LF RIGHT--
PIN 1+...LF RIGHT+
PIN 1--...LF LEFT--
PIN 1+...LF LEFT+
PIN 2--...LF RIGHT--
PIN 2+...LF RIGHT+
PIN 3--...MF/HF--
PIN 3+...MF/HF+
PIN 4--...OUTPUT PIN 2--
PIN 4+...OUTPUT PIN 2+
NEUTRIK
NL 4 MPR
NEUTRIK NEUTRIK
NL 4 MPR
NEUTRIK
NEUTRIK NEUTRIK
NL 8 MPR
NL 8 MPR
Y)
3.500
2.625
510968 (0)
8/24/99
DETAIL B
