Section 3: System Installation and Start-Up
3.1 Installation Procedure
1.
Upon receipt of the system, carefully check each component against the bill of materials to ensu
re
that everything has b
een received with the system. If anything is missing or damaged, immediat
ely
conta
ct the freight company to file the appropriate clai
m.
2.
Remove system from wooden 2 x 4 undercarriage using suitable materials handling equipmen
t.
3.
Install catcher tank sweeper package as shown in the sweeper layout drawing provided
.
4.
Install the gate valve to the suction port on the catche
r tank.
5.
Install the gate valve to the discharge port on the catcher tank
.
6.
Install hose barbs into the suction and discharge gate
valves.
7.
Close the suction and discharge valves.
8.
Fill the catcher tank
with water.
9.
Position system next to waterjet machine as discussed with Ebbco Inc. Anchor system to floor as
necessa
ry.
10.
Using the black suction hose and clamps provided in the installation kit, connect the suction ba
rb on
the catcher ta
nk to the suction barb on the garnet remo
val system.
11.
Using the black discharge hose and clamps provided in the installation kit, connect the discha
rge
barb o
n the catcher tank to the discharge barb on the garnet remo
val system.
12.
Place abrasive bag hopper under purge outlet. Connect decant line to fitting provided on hopp
er.
13.
Connect the overflow piping from the 3" port on the abrasive bag hopper to the garnet pump column
.
14.
Have a qualified industrial electrician connect the 3 phase electrical power to the control panel as pe
r
electri
cal drawing. (230vac/3 ph/60
Hz)
3.2
Start Up Procedure:
1.
Check the pump suction basket for deb
ris.
2.
Open the suction and discharge valves on the catche
r tank.
3.
Ensure that the catche
r tank is full of water.
4.
Check pump for correct rotation (clockwise as viewed from the top of the motor) by bumping t
he HOA
swit
ch, located on the main electrical pa
nel.
5.
The pump motor on the filtration system has been synchronized at the factory if the pump moto
r is
runni
ng in reverse have a qualified electrician swap over one of the in coming line powers at electric
al
panel.
6.
Turn the HOA switch to the HAND po
sition.
Warning! If the filtration system dose not prime after 5 seconds, stop the system. Try three more times
and if the system still will not prime call the Ebbco service department 1-586-716-5151
7.
Check separator inlet and outlet pressure gauges to ensure differential pressure is between 4
and 12
psi.
