EBCHQ YQK-70 User Manual

UNDERSTAND YOUR TOOL
YQK-70 is a tool for connecting lugs and cable. It carries many advantages of good design,
easy operation, high pressure, high efficiency and etc. It is a perfect tool to be used in
electrical construction site.
1. Specification
Crimping range:
Cu 4-70mm
2
Crimping force:
45KN
Crimping type:
hexagon crimping
Stroke:
14mm
Hydraulic oil:
T 15#
Working temperature:
-20℃-40℃
Length:
approx 310mm
Weight:
approx 1.80kg
Package:
plastic box
Weight of box:
approx 0.77kg
Accessories
crimping die:
4, 6, 8, 10, 16, 25, 35, 50, 70 mm
2
sealing O-ring:
one set
The dust or air inside the tool will damage the sealing kit so caused the
tool lose function. Make sure the oil is clear and no dust entering into
oil when changing oil. Wait for a while and exhaust the oil completely
out of the oil tube before inserting the oil plug.
Please wear the rubber gloves to avoid skin touching the oil directly, if touches it in
careless, please wash the skin by soap water in timely. In order to protect the
environment please drain the waste oil to the treatment center where was approved
by government.
Troubleshooting
FAULT
ANALYSIS
SOLUTION
A. No pressure or the
pressure is not enough
during operation
1. The pump lack oil
2. There is dust exist
in oil
3. Inner leakage
1. Fulfill or replace the oil
Change the oil
2. Contact manufacturer or
distributor
B. The lug and wire do
not connect tightly after
crimping.
1. The tool can not
reach to the rated
pressure
2. Use the wrong die
1. Refer to the fault A
2. Replace with the right
die
C. Generate a lot of burs
after crimping
1. Use the wrong die
1. Replace with the right die
D. Oil leakage on the
head or on the ram
1. Sealing kit broken
1. Contact manufacturer or
distributor and replace it by
trained person
