2
31.8mm stent is available 22.2mm25.4mm28.6mm
Transfer Ring Selection
Switching view Switch Side View
二、
Work Voltage and connection mode
1Work voltage DC24V 36V 48V 60V(which you can choose on the
meter),the others you can customized.
2Connection mode
Line sequence of the label connector
Instrument Outlet
