6
9. Three-view Drawing
Top view
Side view
Front view
!
If step 1 failed, follow the below instructions
I. Open the printer cover as showing
III.Press the “FEED”again, cutter will return to its home position.
Attention: Do not use force to separate the printer cover in case of any damage
to the print head and auto cutter.
10. Cutter Maintenance
To Next Page
