Specications:
CAMERA C2013B
Image CMOS
Voltage Requirement 12-24 VDC
E󰀨ective Pixels 976H x 592V
Power Consumption 1W
Lens Size 1/3”
Lens Angle 170°
Audio No
Light Sensor Auto Switch B&W
Infrared LEDs 18
Pigtail Connection: CAM Male 4 Pin Threaded
Housing Aluminum Alloy
Mech. Vibration 8g
Weight 0.58 lbs
Dimensions (WxHxD) 2.92”x3.01”x2.62”
Operating Temp. -4°F to 158°F
IP Rating IP69K
Approvals FCC,CE,RoHS
Current Consumption 175mA Max
MONITOR M7000B
Screen Size 7” (4:3) and (16:9)
Controller 2 Camera
Voltage 12-24 VDC
Power Approximate: 5W
Resolution 800(W)XRGBX480(H)
System PAL/NTSC
Visible Area 154X86mm
Contrast 400:1
Split Screen Feature No
DVR Compatible No
Audio No
Brightness 400cd/m2
Light Sensor Auto Dim
Camera Selection Manual or via AV2 trigger wire
Connection: CAM Female 4 Pin Threaded
Connection (Monitor Pigtail) Male 7 Pin
Housing Plastic
Mounting Pedestal
Weight 0.88 lbs
Dimensions (WxHxD) 6.85” x 4.49” x 0.94”
Operating Temp -4°F to 158°F
Remote Control Yes
Approvals FCC,CE,RoHS
Menu Operations:
Use the touch button icon on the monitor or the Mode Select on the remote to adjust the viewing angle.
Use the touch button icon on the monitor or the Menu Select on the remote. Click menu 7 times to switch between viewing
angles using the arrow key.
Use the touch button icon on the monitor or the center Menu button the remote to toggle between menus. Use the up and down
arrow on the monitor or left to right arrows on remote to increase or decrease each menu function.
Use the touch button icon on the monitor or the Video Select on the remote to adjust view from (AV1) camera 1 to (AV2) camera
2.
OPTION
Rotate
Zoom
To rotate view.
(16:9 or 4:3)
SYSTEM
S-Color
ACC1 - Time
ACC2 - Time
Grid ON/OFF
(Auto, PAL, NTSC)
Trigger 1 timer (0-15 seconds)
Trigger 2 timer (0-15 seconds)
PRESET
Sleep (0-240 mins)
Brightness Adjust brightness setting
Contrast Adjust contrast setting
Saturation Adjust video color
Tint Adjust yellow undertone
Language Select preferred language
Mode Adjust viewing angle
Rotate Adjust viewing
Reset Reset to factory setting
