Ecco K7000B - Monitor and Remote Operation; Monitor Installation and Parts; Remote Control Identification

Page 3 of 5
Remote:
Monitor:
Model M7000B
Installation instruction of using pedestal base:
1. Select suitable position on vehicle and x the base support.
2. Fix the monitor to the base support and adjust the view angle.
3. Attach the sun-visor to monitor
4. Connect the monitor to the power harness (provided with kit)
Monitor Parts Identication
WARNING!
To prevent accidental shock, DO NOT OPEN THE MONITOR CASE. Opening the monitor case will expose the inside of the monitor to
conditions that could adversely a󰀨ect performance. Any evidence of tampering with sealed components will void the warranty.
Important! Do not expose the monitor to water, it is not waterproof. Any water that leaks into the monitor could cause extensive damage.
