Levelling the washing machine
1. Make sure that the feet t tightly against the cabinet. If not, turn them to their original position and tighten
the nuts.
2. Loosen the lock nut and turn the foot until it touches the oor.
3. Adjust the feet and secure them with a wrench; make sure the machine is stable.
Lift
Lower
Nut
Leg
• The lock nuts on all four legs must be tightened to the bottom.
Connecting the water supply hose
• Follow the instructions in this chapter to protect against water leakage!
• Do not bend, crush, modify or disassemble the supply hose.
Note:
The washing machine must be connected to the water supply only using the new supplied supply hose.
Old hoses must not be reused.
The ideal water supply pressure is between 0.05 MPa and 1 MPa.
Connect the supply hose as indicated; There are two ways to connect the supply hose.
1. Connection between ordinary tap and supply hose.
clamping nut
Loosen the clamping
nut and the four bolts
Tighten the
clamping nut
Squeeze the sliding
sleeve, insert the
supply hose into the
connection base
Connection completed
sliding sleeve
2. Connection between screw tap and supply hose.
Threaded tap and supply hose Special tap for washing machine
sliding sleeve
Connect the other end of the supply hose to the inlet valve on the back of the appliance and tighten the hose
clockwise.
