STANDARD SYSTEM FEATURES
Aluminum vertical frame with shock mounted Duplex stainless steel high pressure pump, control panels
and RO vessels
2 Filter housings with pleated polyester cartridges, 5 and 20 microns, 41/2” x 10”
1 Filter wrench
Manual fresh water flush system
Pressure vessel(s) with reverse osmosis membrane(s)
ECH
O Tec. 1000-BHL-2
two 40” vessels
1300-BHL-3
three 40” vessels
1800-BHL-4
four 40” vessels
Instruments
The desalination system is equipped with all necessary instrumentation, for the control and supervision of
the operation of the unit.
The instrumentation includes:
Pressure Gauges:
Feed water, system entrance (316SS glycerin filled)
Feed water, high pressure pump entrance (316SS glycerin filled)
RO pressure, (316SS glycerin filled)
Flow Meter:
Product discharge
Conductivity:
Digital product water quality monitor - ppm TDS
The following automatic emergency shut off functions are provided:
Low feed water pressure (e.g. seawater intake or pre-filters clogged)
High RO pressure
Tank full (float switch optional)
1 Fresh water flush filter with active carbon cartridge
1 Hardener / pH neutralizer kit with mineral element and 2pcs 3/8” compression fittings
1 Stainless steel bracket with 8 screws
20 feet / 6 meter 1/2” reinforced vinyl hose (reject, product, flush)
10 feet / 3 meter blue product water tubing (membrane to flow panel)
10 feet / 3 meter 3/4” reinforced vinyl hose (pre-filter to high pressure pump)
3 feet / .9 meter 5/8” service intake hose
6 1/2" Stainless steel hose clamps
1 5/8” Stainless steel hose clamp
2 3/4” Stainless steel hose clamps
1 Handheld TDS Meter
1 Biocide, 1 acid cleaning solution, 1 alkaline cleaning solution
1 Owners Manual
