Echo 99944100025 - Assembly Instructions; Connect Extension Tubes and Nozzle

2
RAIN GUTTER KIT
99944100025
4
2
2
3
1
1
KEY PART NUMBER QTY DESCRIPTION REMARKS
1 21041304260 2 Clamp
2 21001504260 2 Straight Pipe
3 21002304260 2 Elbow Nozzle
4 E165000230 1 Adapter
ASSEMBLY INSTRUCTIONS
1. Connect 2 long tubes (2). Secure tubes with clamp (1).
2. Connect 2 elbows (3) that make up adjustable nozzle.
3. Install the adjustable nozzle to the small end of extension
tube (2).
2
1
3
3
3
2
