Echo CS-3400 Type 1E - Page 3

3
ITEM PART NUMBER QTY DESCRIPTION REMARKS
CS-3000 TYPE 1, 1E
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
17
18
21
22
23
24
25
25
26
27
28
OPTIONAL ENGINE REPOWER
SB1018 1 SHORT BLOCK INCLUDES 2-16
------------------- 1 CRANKCASE SET INCLUDES ITEM 3
90023805025 4 SCREW 5X25
V103000120 1 GASKET, INTAKE
14551013931 1 GASKET, EXHAUST
10000039130 1 PISTON KIT INCLUDES ITEMS 7-10
10001146430 1 RING, PISTON
10001315330 1 PIN, PISTON
10001504630 2 CIRCLIP, PISTON PIN
10001411520 2 SPACER, PISTON PIN
17501203930 1 BEARING, NEEDLE
10014239130 1 KEY, WOODRUFF
------------------- 1 CRANKSHAFT ASY INCLUDES ITEMS 14-16
10021338330 2 SEAL, OIL
90081036201 2 BEARING, BALL 6201
43706338330 1 GEAR, WORM
TYPE 1 - S/N 001001 & UP, TYPE 1E - S/N 001001-665925, CANADA - S/N 001001-004033
10400439231 1 COVER KIT, ENGINE INCLUDES ITEMS 18-22
43301103931 2 STUD, GUIDE BAR
10421539131 1 LATCH
90025304010 1 SCREW 4X10
TYPE 1E - S/N 665926 & UP, CANADA - S/N 004034 & UP
A190000020 1 COVER KIT, ENGINE INCLUDES ITEM 18
43301103931 2 STUD, GUIDE BAR
S/N 001001 & UP
16391139130 1 PLUG, OILER
10403439130 1 PLUG
10402939230 1 GROMMET
90010605016 4 BOLT 5X16
12901039130 1 GROMMET, NEEDLE -- TYPE 1
17881039630 1 GROMMET, CHOKE -- TYPE 1E
12902339130 1 GROMMET, IDLE
10404439230 1 COVER
90025604016 1 SCREW 4X16
ENGINE, SHORT BLOCK, ENGINE COVER
