Echo CS-3400 Type 1E - Page 9

9
ITEM PART NUMBER QTY DESCRIPTION REMARKS
CS-3000 TYPE 1, 1E
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
13130056430 1 VALVE, CHECK
13132839130 1 COVER, VENT
13201004920 1 PIPE, VENT - 3X5X150 BULK OPTION: 90014
13211539130 1 GROMMET, FUEL
13201239130 1 PIPE, FUEL - 3X6X160mm BULK OPTION: 90015
13201326630 3 CLIP
13120507320 1 FILTER, FUEL
12318139130 1 PUMP, PURGE
89016739230 1 LABEL, PURGE PUMP
89022839130 1 LABEL, CAUTION
13275839130 1 BRACKET, PUMP
13271639130 1 PIPE, RETURN - 2X4X42 BULK OPTION: 90018
13131239130 1 PIPE, PURGE - 3X5X70 BULK OPTION: 90014
43600139231 2 CAP, TANK INCLUDES ITEMS 15-16
90072100025 2 O-RING 25
13105119830 2 CLIP, FUEL CAP
13033639530 1 PLUG
43611413930 1 VALVE, CHECK
43720139130 1 PIPE KIT INCLUDES ITEM 20-21
43724439130 1 PAD, FOAM
43721139132 1 PIPE, OIL
43700239130 1 AUTO-OILER ASY INCLUDES ITEM 23-29
12312715030 1 CLIP
43701938330 1 SPRING
43702437330 1 PLUNGER
43706237330 1 CAP, OIL PUMP
43701537330 1 SPRING
43702937330 1 WASHER
43701639130 1 NEEDLE, ADJUST
90023505012 2 SCREW 5X12
13201235430 1 PIPE - 3X6X115 BULK OPTION: 90015
13211501461 1 GROMMET
43620502832 1 STRAINER, OIL
FUEL SYSTEM, OIL SYSTEM
