REMARKSDESCRIPTIONQTYPART NUMBERITEM
COIL, IGNITION1A4110002641
SCREW - 5X202900162050202
LEAD - GROUND1V4850006203
LEAD - IGNITION1V4850006804
CLIP1V4900003105
GROMMET1150114049206
SPACER2150117164307
GROMMET1V1350000108
CAP, SPARK PLUG1A4270000139
TERMINAL, SPARK PLUG CAP1A42600001010
SPARK PLUG -- BPM-8Y11590101983011
CANADA MODELSSPARK PLUG -- BPMR-8Y1A42500000012
FLYWHEEL1A40900027213
KEY, WOODRUFF11001421233014
NUT - 8 -- FLANGE19005150000815
99922204126 - 13 - REVISED 03/02/11
Table of Contents Part Number Index
CS-400 Chain Saw Ignition, Flywheel

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo CS-400 - SERIAL NUMBER C08111001001-C08111999999 and is the answer not in the manual?

Echo CS-400 - SERIAL NUMBER C08111001001-C08111999999 Specifications

General IconGeneral
Engine Displacement40.2 cc
Engine Type2-stroke
Oil Capacity8.5 fl oz (250 ml)
Weight10.1 lbs
Power Output2.3 hp (1.7 kW)
Chain Pitch3/8 inch
Chain Gauge.050 in
