REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-10CHAIN BRAKE ASY1C0320002821
GUARD, SPROCKET1C3000003122
CONNECTOR, BRAKE1C3340000903
BAND, BRAKE1C3280000804
GUIDE1V3760004505
SPRING1V4500000706
SPACER1433116354307
ROLLER193050300988
COVER, BRAKE1C3450002119
SCREW - 4X12 -- TAPPING3V20200006010
LEVER, BRAKE1C32000011111
SCREW - 4X161V20200007012
WASHER11772140393013
SPACER14331163543014
SPRING1V45200025015
COLLAR1V35600030016
SCREW - 5X161911450501617
BOLT1V20300011018
TENSIONER, CHAIN1C30900003019
GEAR, BEVEL1V65100000120
COLLAR - 81V35500027021
GEAR, BEVEL1V65100001122
NUT -- FLANGE24330191233023
PLATE, GUIDE - OUTER1C30500001124
SCREW - 3X619002200300625
SCREW - 4X12 -- TAPPING2V20200006026
PLATE, GUIDE - OUTER14330123993027
BUMPER, SPIKED1C30400001028
SCREW - 5X202911450502029
CATCHER, CHAIN1C31000000030
SCREW - 5X161911450501631
99922204125 - 15 - REVISED 03/02/11
Table of Contents Part Number Index
CS-400 Chain Saw Chain Brake
