Echo CS-400 - SERIAL NUMBER C09011001001-C09011999999 User Manual

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-13SHORT BLOCK -- SB10891SB10891
INCLUDES ITEM 3CRANKCASE SET1------------------2
SCREW - 5X224900162050223
INCLUDES ITEMS 5-9PISTON KIT1P0210105814
RING, PISTON1A1010001605
PIN, PISTON1V6070000006
RING, RETAINING2100015039317
BEARING, NEEDLE1100012161318
SPACER, PISTON PIN2100014536309
INCLUDES ITEMS 11-13CRANKSHAFT ASY1P02100984010
GEAR, WORM
1
1V65200001011
BEARING, BALL - 62012940353620112
SEAL, OIL2V50500001013
SCREW - 5X3049001620503014
Footnotes
1: ALSO INCLUDED IN P021001980 - AUTO-OILER ASY
99922204125 - 23 - REVISED 03/02/11
Table of Contents Part Number Index
CS-400 Chain Saw Engine, Short Block -- SB1089

Echo CS-400 - SERIAL NUMBER C09011001001-C09011999999 Specifications

General

Engine Displacement	40.2 cc
Weight	10.1 lbs
Chain Pitch	3/8 inch
Chain Gauge	0.050 in.
Warranty	5 year consumer / 2 year commercial
Guide Bar Length	16-20 inches
