CS-6703(36)
6. Auto-Oiler
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
31 900603-00005 1 WASHER 5 5.5*12*0.8
32 900252-05020 1
SCREW 5*20
5*20
33 437413-19830 1
BARCKET, OIL PUMP
34 900252-04010 1
SCREW 4*10
4*10
37 437216-32630 1
PIPE, OUTLET
38 437232-32630 1
CONNECTOR, OIL PIPE
39 437212-32630 1
CONNECTOR, OIL PIPE
45 437002-37530 1
AUTO-OILER ASSY
- 12 -
