REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- C1U-K781A021000940
SCREW, METERING DIAPHRAGM
COVER
2125344521301
COVER, METERING DIAPHRAGM1125342132102
NOT AVAILABLE SEPARATELYBODY, CARBURETOR1------------------3
NOZZLE, CHECK VALVE1125376131204
CAP, MIXTURE LIMITER - HIGH SPEED1125329085605
NEEDLE - HIGH SPEED1P0050004006
SHAFT, THROTTLE1P0050017707
SPRING, THROTTLE RETURN1125313420308
SCREW, THROTTLE VALVE1125314139309
VALVE, THROTTLE11253164903010
CLIP, THROTTLE SHAFT11253271393011
LEVER, THROTTLE11253502056012
SCREW THROTTLE LEVER11253481393013
SCREW, IDLE ADJUST11253340686014
PIECE, FRICTION11253781393015
BASE, PURGE1P00500099016
BULB, PURGE11253810866017
RETAINER, PURGE PUMP11253631161018
SCREW, PURGE BASE21253101161019
SCREW, METERING LEVER PIN11253394203020
INCLUDES ITEMS 23-32REPAIR KIT1P00500180021
DIAPHRAGM, METERING1------------------22
GASKET, METERING DIAPHRAGM1------------------23
PIN, METERING LEVER1------------------24
LEVER, METERING1------------------25
VALVE, INLET NEEDLE1------------------26
SPRING, METERING LEVER1------------------27
WELCH PLUG1------------------28
STRAINER1------------------29
DIAPHRAGM, FUEL PUMP1------------------30
GASKET, FUEL PUMP1------------------31
INCLUDES ITEMS 34-37DIAPHRAGM/GASKET KIT1P00500179032
DIAPHRAGM, METERING1------------------33
GASKET, METERING DIAPHRAGM1------------------34
DIAPHRAGM, FUEL PUMP1------------------35
GASKET, FUEL PUMP1------------------36
