1. Battery Terminal Grooves
2. Ventilation Grills
3. Charging Indication Panel
4. Electrical Cord
5. Charger mounting hole
CHARGER TERMS
• BATTERY TERMINALS GROOVES - Electrical connection
between battery and charger.
• VENTILATION GRILLS - Cool down the charger.
• CHARGE INDICATION PANEL - Charging status.
DESCRIPTION
