REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-21SHORT BLOCK -- SB10471SB10471
CYLINDER1A1300001222
SCREW - 5X224900162050223
GASKET, CYLINDER
1
1V1000000104
INCLUDES ITEMS 6-9PISTON KIT1P0210023605
RING, PISTON2A1010000106
PIN, PISTON1V6060000007
2 RING, RETAINING2100015046308
SPACER, PISTON PIN2100014559309
BEARING, NEEDLE1V55300002010
CRANKSHAFT ASY1A01100003011
INCLUDES ITEMS 13-18CRANKCASE KIT1P02100094012
SEAL, OIL11002130553013
BEARING, BALL - 600129008003600114
RING, RETAINING - 2819007020002815
GASKET, CRANKCASE
1
11002425593016
SCREW - 5X2549001620502517
SEAL, OIL11002122823018
SHIELD, EXHAUST1V10400006119
GASKET, INTAKE
1
11300105593020
GASKET, INTAKE
1
11300101341021
Footnotes
1: Also Included In GASKET KIT
99922203284_260/04 - 21 - REVISED 02/03/11
Table of Contents Part Number Index
PPT-260 Power Pruner Engine, Short Block -- SB1047
