15
UNPACKING & ASSEMBLY
• The adjustable spray nozzle had has two (2) positions (Fig. 10):
Fig.10
High pressure setting
IN position
IN position
Pencil Spray
Pencil Spray
Fan
Spray
OUT position
OUT position
High pressure
setting
Low pressure setting
Low pressure setting
IN position for high pressure spray. Twist the nozzle counterclockwise until it stops
and gap is closed.
OUT position for low pressure spray for detergent function. Twist the nozzle
clockwise until it stops and gap is open.
• When using the High Pressure setting twist the nozzle head clockwise or
counterclockwise to achieve the stream desired.
• When using the Low Pressure setting twist the nozzle head clockwise to open the
fan blades all the way.
When applying detergent using low pressure spray, the
variable spray head must be set for the “Pencil Stream”. This is when the metal
blades in front of the nozzle is wide open so the detergent spray is not constricted.
• When using the detergent, ll it with a properly formulated detergent or cleaner
with water ratio according to instructions on the container (Fig. 11). The detergent
tank comes with a straw which is tted into the screw-on top. If you don’t see the
straw, look inside the tank and attach it to the screw-on top (Fig. 12).
• When removing the detergent tank remove lid and place nger in tank lifting up
while pulling tank out.
Fig.11
Fig.12
