ASSEMBLY ES-250
2. Align locking ribs (A) on elbow pipe with recesses (B) in fan
case. Assure short locking rib (C) faces downward. Slide
elbow pipe into fan case until a clicking sound is heard.
3. Place debris bag opening over flared end of elbow (D), and
cinch bag securely with Velcro strap (E).
B
A
C
D
E
