Echo SRM-260 - PARTS CATALOG SERIAL NUMBERS 04001001-04999999 User Manual

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- WYJ-250A1A021000051
SCREW, CABLE BRACKET2123114406301
BRACKET, CABLE1P0030001802
NOT AVAILABLE SEPARATELYTHROTTLE VALVE ASY1------------------3
SCREW, IDLE ADJUST1123134400304
SWIVEL1123172451305
WASHER1123149542306
CLIP, SWIVEL1123173079307
BODY, CARBURETOR
1
1------------------8
O-RING1123183406309
JET1P00300026010
INCLUDES ITEMS 12-17PUMP BODY ASY11231790556011
SCREEN, INLET1------------------12
SCREW, METERING LEVER PIN11231390556013
VALVE, INLET NEEDLE1------------------14
SPRING, METERING LEVER11231220556015
PIN, METERING LEVER11231380393016
LEVER, METERING1------------------17
BODY, AIR PURGE11231800556018
BULB, PURGE11231814063019
COVER, PRIMER PUMP11231420556020
SCREW, PUMP COVER41231100556021
INCLUDES ITEMS 23-30REPAIR KIT1P00300019022
PACKING, RING1------------------23
GASKET, PUMP1------------------24
DIAPHRAGM, PUMP1------------------25
SCREEN, INLET1------------------26
VALVE, INLET NEEDLE1------------------27
LEVER, METERING1------------------28
GASKET, METERING DIAPHRAGM1------------------29
METERING, DIAPHRAGM1------------------30
INCLUDES ITEMS 32-36GASKET/DIAPHRAGM KIT1P00300020031
PACKING, RING1------------------32
GASKET, PUMP1------------------33
DIAPHRAGM, PUMP1------------------34
GASKET, METERING DIAPHRAGM1------------------35
METERING, DIAPHRAGM1------------------36
Footnotes
1: NOT AVAILABLE SEPARATELY
99922203538_260/04 - 15 - REVISED 10/22/08
Table of Contents Part Number Index
SRM-260 Trimmer Carburetor -- WYJ-250A
