REMEMBER THE LAST TIME
YOU “WINGED IT”?
M4 x 12mm
M4 x 35mm
WARNING: DON'T FEED TO CHILDREN
—
This product contains small items that could be a choking
hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are
missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
Never use damaged parts!
What’s in the Box ... what's in the boooox
NOTE: Not all hardware included in this kit will be used.
STUFF FOR STEP 1
TV Screws (qty. 4 each)
[Only one size fits your TV]
Washers Spacers
[If necessary]
TV
Brackets
qty.8
Secure
Screw
(attached)
qty.2
qty.4
qty.4
qty.4
qty.4
M6
M4
M8/M6
M4
M8
01
02 03
s
04
To Next Page
