4
Installation Guide
Button Reference (Monitor)
Button Reference (Remote)
PMON-7022-AHD
7” Dash Mount 2 Input AHD Monitor
1
2 3 4 5 6 7 8 9
1. Sunshade 7 . CH2
2. Down Arrow 8. MODE Button
3. MENU Button 9. IR for Remote
4. Up Arrow
5. POWER Button
6. CH1
1. POWER Button
2. CH1/CH2 Video Select
3. Menu Selection (+)
4. MENU Button
5. Menu Selection (-)
6. MODE Select
1
2
5
3
4
6
