Installation Guide
email - gmsupport@echomaster.com (US) - tel - 866-766-2267email - gmsupport@echomaster.com (US) - tel - 866-766-2267
RVC-W8
Wireless Camera & Receiver Kit
Camera (with built-in TX)
Image device HM1240
Lens specification 1/4inch 4G
Horizontal angle 90° ± 5°
Vertical angle 50° ± 5°
Imaging resolution 1024 x 600 Pixel
Minimum illumination 0 Lux / (infrared LED on)
Transmission power 18 ± 2 dBm
Working frequency 2.4GHz ~ 2.4835GHz
Antenna gain 2.0 dBi @ 2400 ~ 2500MHz
System IEEE 802.11 b/g/n
Length of cable 36 in
Current consumption <=350mA
Power supply DC 12/24V
Operating temperature -20°C to 65°C
Specifications
