- 4 -
the guide bar up and back towards the operator. Pinching the saw chain along the top of the guide bar may push the
guide bar rapidly back towards the operator. Either of these reactions may cause you to lose control of the saw that
could result in serious injury to user. The following precautions should be followed to minimize kickback.
① . Grip Saw Firmly.
Hold the chain saw firmly with both hands when the motor is running. Use a firm grip with thumbs and fingers
encircling the chain saw handles.
②. Do not over reach.
③. Keep proper footing and balance at all times.
④. Don’t let the nose of the guide bar contact a log, branch, ground or other obstruction.
⑤. Don’t cut above shoulder height.
⑥. Use devices such as low kickback chain, guide bar nose guard, chain brakes and special guide bars that reduce
the risks associated with kickback.
⑦. Only use replacement bars and chains specified by the manufacturer or the equivalent.
20. Power Supply. Connect chain saw to correct voltage, that is, be sure that the voltage supplied is the same as
that specified on the nameplate of the tool.
Technical Data
Parts Identification
1 Cable + plug
2 Rear handle
3 On/Off switch
4 Lock-off button
5 Oil Tank cap
6 Front handle
7 Activation lever for kickback brake (hand guard)
8 Nose sprocket
9 Chain bar
10 Chain
11 Gripping teeth
12 Tensioning ring
13 Lock knob
14.Cover plate
15 Oil outlet
16 Cable hook
17 Chain guard
Nominal Voltage 230-240V~50Hz
Chain Saw DB6021S / ECS01
Rated Power 2200 W
Length of Oregon Bar 18” / 457 mm
Tool-less Oregon Chain Tensioning ( SDS) YES
No Load Speed 5800rpm
Chain Speed 13 m/s
Front Brake Time 0.15 sec
Oil Tank Capacity (With Automatic /Regulated
Lubrication) 300 ml
Noise Level 107 Db
Vibration 1.5 m/s
2
Net Weight 5.3 kg
Protection Class Double Insulation
