Ecler APA2000 Service Manual

author: Queralt date: 000913
approved:
num:
40.0050 version: 01.00
C101 22p FCXCN12200
C102 100n FCXCN41000
C103 47u/50 FCCE250470
C104 10u/50 FCCE250100
C105 47p FCXCN14700
C106 47p FCXCN14700
C107 47u/100 FCCE350470
C108 47u/100 FCCE350470
C109 10u/50 FCCE250100
C110 100n FCXCN41000
C111 15p FCXCN11500
C112 100n FCXCN41000
C113 10u/50 FCCE250100
C114 470n FCXCN44700
C115 470n FCXCN44700
C116 12p FCXCN11200
C117 12p FCXCN11200
C118 C220n/100V FCCDK52200
C119 C220n/100V FCCDK52200
C120 47u/100 FCCE350470
C121 47u/100 FCCE350470
C122 680p FCXCN26800
C123 680p FCXCN26800
C124 C1u/63V FCCDK20010
C125 10n FCXCN40100
C126 10n FCXCN40100
C127 C100n/400V FCCDH71100
C128 C47n/400V FCCDH71047
C129 100n FCXCN41000
C130 100n FCXCN41000
C131 10u/50 FCCE250100
C132 470n FCXCN44700
C133 10u/50 FCCE250100
C134 470u/25 FCCE154700
C135 10u/50 FCCE250100
C136 470n FCXCN44700
C137 47u/16 FCCE100000
C138 47u/50 FCCE250470
C139 100n FCXCN41000
C140 100n FCXCN41000
C141 100n FCXCN41000
C142 47u/50 FCCE250470
D101 BAS16 FCXDDBAS16
D102 BAS28 FCXDDBAS28
D103 Z7.5V FCXZ000075
D104 BAS28 FCXDDBAS28
D105 Z3.9V FCXZ000039
D106 Z3.9V FCXZ000039
D107 Z12 FCDD041200
D108 Z12 FCDD041200
D109 Z18V FCXZ000180
D110 Z18V FCXZ000180
REFERENCE VALUE CODE
PARTS LIST
PRINTED CIRCUIT 11.0766-01.02
model:
EP03-99D
E
C
LER
40-0050-0100 EP03-99d.xls SHEET 1 OF 6
