EC 90 - Chassis Components
15
ID CODE QTY DESCRIPTION ID CODE QTY DESCRIPTION
1 BIO097VD 1 MACHINE BODY 16 40100281 4 SCREW UNI 5739 M10X16
2 BIO098VD 1 FRAME 17 40100100 2 SCREW UNI 5931 M8X130
3 BIO122VD 1 HOPPER 18 40100139 2 SCREW UNI 5933 M8X25 HARDTEMPERED
4 BIO385VD 1 FRONT FLANGE 19 40100298 8 SCREW UNI 5931 M10X25
5 BIO324VD 1 PVC SHEILD LOCK 21 40300003 20 WASHER D10 UNI 6592
6 BIO377D 1 PVC SHEILD 23 40300031 9 WASHER D8X24
7 BIO311VD 1 SCREEN 24 40300002 2 WASHER D8 UNI 6592
8 BIO338D 1 FIXED KNIFE 26 40300014 6 WASHER D6X24
9 BIO555ZD 2 SILENT BLOCK SUPPORT 28 40300002 2 WASHER D8X24
10 BIO580ZD 2 WHEEL AXLE 29 SRM203ZD 2 SPACER 25,5X35X2
11 41800018 1 PLASTIC HANDLE M10 31 40200003 8 NUT M10 DIN 980
12 42900002 2 TIRE WHEEL 32 40200040 12 SELFLOCKING NUT M8 DIN 982
13 42500018 2 SILENT BLOCK 33 40200010 4 NUT ME UNI 5589
14 40100143 3 SCREW UNI 5739 M6X25 36 40200051 3 SELFLOCKING NUT M6 DIN 982
15 40100029 1 SCREW UNI 5739 M8X30 38 41300002 2 SPRING PIN D6
