EC 90 - Drivetrain Components

ID CODE QTY DESCRIPTION

1 BIO105VD 1 SAFETY CARTER 15 BIO110D 1 CLUTCH STAR

2 BIO086VD 1 SAFETY CARTER BRACKET 16 40400019 1 SEEGER I62 UNI 7437

3 BIO327VD 1 PROTECTION FLANGE 17 41000054 1 BEARING 6007 2RS

4 BIO090ZD 1 TENSIONER 18 40400021 1 SEEGER E35 UNI 7435

5 BIO091ZD 1 PLATE WITH SCREWS 19 40100300 4 SCREW UNI 5931 M6X25

6 BIO367D 1 PULLEY 120-1B 20 40100135 1 SCREW UNI 5739 M10X100

7 BIO106D 1 COMPLETE CLUTCH

21 40100307 4 SCREW UNF 5/16X5/8

8 42800033 1 V-BELT B24 22 40100011 7 SCREW UNI 5739 M8X15

9 BIO554ZD 1 CLUTCH SPACER 23 40100309 1 SCREW UNF 5/16X1” 1/2

10 BIO369ZD 1 CLUTCH STOPPER 24 40300002 7 WASHER D8 UNI 6592

11 SRM204ZD 1 SPACER 25,5X35X6 25 40300031 5 WASHER D8X24

12 BIO590VD 1 CLUTCH BELL 26 40300013 1 WASHER D10X30

13 BIO592VD 1 CLUTCH BODY 27 40200040 4 SELF LOCKING NUT ME DIN 982

14 BIO250D 1 CLUTCH RUBBER STAR
