EC 120 - Drivetrain Components
19
ID CODE QTY DESCRIPTION ID CODE QTY DESCRIPTION
1 BIO107VD 1 SAFETY CARTER 17 41000054 1 BEARING 6007 2RS
2 BIO108VD 1 SAFETY CARTER BRACKET 18 40400021 1 SEEGER E35 UNI 7435
3 BIO578VD 1 PROTECTION FLANGE 19 40100300 4 SCREW UNI 5931 M6X25
4 BIO588VD 1 COUNTERWEIGHT 20 40100023 2 SCREW UNI 5739 M12X40
5 BIO094ZD 1 PLATE WITH SCREWS 21 40100307 4 SCREW UNF 5/16X5/8
6 BIO093ZD 1 TENSIONER 22 40100135 1 SCREW UNI 5739 M10X100
7 42800035 1 V-BELT B25 23 40100011 3 SCREW UNI 5739 M8X15
8 BIO109D 1 COMPLETE CLUTCH 24 40100310 1 SCREW UNF 3/8X1”
9 SRM196D 1 PULLEY 180-1B 25 40300003 1 WASHER D10 UNI 6592
10 BIO349ZD 1 CLUTCH STOPPER 26 40300002 2 WASHER D8 UNI 6592
11 SRM203ZD 2 SPACER 25,5X35X2 27 40300031 3 WASHER D8X24
12 BIO590VD 1 CLUTCH BELL 28 40300013 4 WASHER D10X30
13 BIO591VD 1 CLUTCH BODY 31 40300045 4 WASHER D12X36
14 BIO250D 1 CLUTCH RUBBER STAR 32 40200006 2 NUT M12 DIN 980
15 BIO110D 1 CLUTCH STAR 33 40200038 4 SELFLOCKING NUT M10 DIN 982
16 40400019 1 SEEGER I62 UNI 7437
