Ecoflam Max Gas 120 P AB User Manual

420010386101 Max Gas 70-105-120 P AB420010386102 Max Gas 70-105-120 P AB
pag.10
TC = SHORT HEAD TL = LONG HEAD
MAX GAS 70 PAB
N° DESCRIPTION
code
1 AIR PRESSURE SWITCH LGW10A2P 65323047
2 AIR INTAKE SET -
3 BURNER COVER 65320602
4 MOTOR 75 W 65325327
5 CAPACITOR 3 µF AEG 65321857
5 µF SIMEL 65325038
6 GASKET 65321109
7 FAN 120 x 50 65321770
8 AIR DAMPER 65325146
9 FAN SCOOP 65320621
10 AIR INTAKE 65325147
11 CONTROL BOX BASE LANDIS 65320092
12 CONTROL BOX LANDIS LGB 22 65320034
13 IGNITION TRANSFORMER 65323258
14 WIRING TERMINAL BOX -
15 COVER 65320663
16 ANTIJAMMING FILTER -
17 ORING 65321061
18 IONIZATION CABLE TC 65322006
TL 65322006
19 IGNITION CABLE TC 65320934
TL 65320936
20 IONIZATION PROBE 65320905
21 IGNITION ELECTRODE 65325241
22 ROD TC 65320162
TL 65320163
23 SUPPORT PIPE TC 65321528
TL 65321529
24 FIRING HEAD 65321568
25 HEAD CAP 65321569
26 DIFFUSER 65320761
27 TOOTH G20-25 65325238
G30-31 65325239
28 BLAST TUBE TC 65320311
TL 65320312
29 INNER ASSEMBLY G20-25 65322572
G30-31 65324794
30 FLANGE 65320972
31 CARTER -
32 PLUG WIELAND 7 pin 65322069
4 pin 65322065
33 SOCKET WIELAND 7 pin 65322070
4 pin 65322068
34 AIR DAMPER MOTOR Landis SQN75.224A21 65106029
35 NEEDLE 65325240
