Ecoflam Max Gas 120 P AB User Manual

420010386101 Max Gas 70-105-120 P AB 420010386102 Max Gas 70-105-120 P AB
pag.11
TC = SHORT HEAD TL = LONG HEAD
MAX GAS 105 PAB MAX GAS 120 PAB
N° DESCRIPTION
code code
1 GAS PRESSURE SWITCH LGW10A2P 65323047 65323047
2 AIR INTAKE SET - -
3 BURNER COVER 65320602 65320602
4 MOTOR 75 W
65325327 65325327
5 CAPACITOR 3 µF AEG 65321857 65321857
5 µF SIMEL 65325038 65325038
6 GASKET 65321109 65321109
7 FAN 120 x 50 65321770 65321770
8 AIR DAMPER 65325146 65325146
9 FAN SCOOP 65320621 65320621
10 AIR DAMPER MOTOR SUPPORT 65325147 65325147
11 CONTROL BOX BASE LANDIS 65320092 65320092
12 CONTROL BOX LANDIS LGB 22 65320034 65320034
13 IGNITION TRANSFORMER 65323258 65323258
14 WIRING TERMINAL BOX - -
15 COVER 65320663 65320663
16 ANTIJAMMING FILTER - -
17 ORING 65321061 65321061
18 IONIZATION CABLE TC 65322006 65322006
TL 65322006 65322006
19 IGNITION CABLE TC 65320934 65320934
TL 65320936 65320936
20 IONIZATION PROBE 65320905 65320905
21 IGNITION ELECTRODE 65325241 65325241
22 ROD TC 65320164 65320164
TL 65320165 65320165
23 SUPPORT PIPE TC 65321530 65321530
TL 65321531 65321531
24 FIRING HEAD 65321568 65321568
25 HEAD CAP 65321569 65321569
26 DIFFUSER 65320761 65320761
27 TOOTH G20-25 65325238 65325238
G30-31 65325239 65325239
28 BLAST TUBE TC 65320313 65320317
TL 65320314 65320318
29 INNER ASSEMBLY G20-25 65322572 65322572
G30-31 65324794 65324794
30 FLANGE 65320972 65320972
31 CARTER - -
32 PLUG WIELAND 7 pin 65322069 65322069
4 pin 65322065 65322065
33 SOCKET WIELAND 7 pin 65322070 65322070
4 pin 65322068 65322068
34 AIR DAMPER MOTOR Landis SQN75.224A21 65106029 65106029
35 NEEDLE 65325240 65325240
