Overview - Dimensions / Panoramica - Dimensioni / Vue d'ensemble - Dimensions / Descripción - Dimensiones / Обзор - Размеры
X
Y
Z
Packaging
MAX GAS 40
GAS TRAIN DIMENSIONS: refer to GT manual
Ø r
RrSr
d..°
Ø a Ø b
Ø c
125
153
M
MAX GAS 70-105-120
d..°
Ø a Ø b
Ø c
125
M
MAX GAS 40
CB
A
E
D-D1
F
G
M
126
151
I
L
Max Gas 70P-120P
NP
O
MAX GAS 70 - 105 - 120
A
BC
D-D1 E
M
125
I
L
G
F
N
O
Model
A
B C
D D1
E F G
I L M
N O P
MAX GAS 40 P 288 143
145 85 185
153 89 160
92/107
92/107 M8 54 73 -
MAX GAS 70 P 303 155
148 85 185
204 89 160
100/120
100/120 M8 52 71 82
MAX GAS 105 P 317 169
148 140 220
255 89 160
100/120
100/120 M8 52 71 82
MAX GAS 120 P 317 169
148 160 240
255 98 160
100/120
100/120 M8 52 71 82
Model Ø a Ø b
Ø c d°..
MAX GAS 40 P
100 130
150
45°
MAX GAS 70 P
110 140
170
45°
MAX GAS 105 P
110 140
170
45°
MAX GAS 120 P
110 140
170
45°
Model
X
Y
Z Kg
MAX GAS 40 P 415 400
310
8,5
MAX GAS 70 P 400 520
300
9
MAX GAS 105 P
400
520
300
9,5
MAX GAS 120 P
400
520
300
9,5
