Ecoflo Coco Filter EC7 Series - Technical Datasheets for Models 2.8, 3.4, 4.1

1.1 Technical datasheets of models 2.8, 3.4 and 4.1 including the PACK option
Table 1 Technical Data Sheet 2.8 model
* Refer to the drawings on Figure 1.
** The weights indicated are approximate (non-contractual) and provided for handling and lifting purposes only.
NOTE: Refer to the dosage volume chart for the Ecoflo
®
Coco Filter model.
Model
Ecoflo
®
Coco Filter 2.8
Ecoflo
®
Coco Filter 2.8
PACK option
Hydraulic capacity
500 US gal/d
(1,900 L/d)
500 US gal/d
(1,900 L/d)
Actual volume of the primary/septic tank
N/A
750 US gal
(3,000 L)
Effluent filter in the primary/septic tank
N/A
Polylok PL-122
Mode of discharge
Gravity
Pumped
Gravity
Pumped
Type of bottom
Watertight
Watertight
Watertight
Watertight
Length (A)*
10'3" (3,120 mm)
10'3" (3,120 mm)
Width (B)*
4'2" (1,280 mm)
7'9" (2,360 mm)
Height (C)*
5'10" (1,770 mm)
5'10" (1,770 mm)
Inlet invert height (D)*
4'1" (1,230 mm)
4'4" (1,285 mm)
Inlet invert height (E)*
1'9" (540 mm)
1'7" (485 mm)
Outlet invert height (Fg and Fp)*
1¾" (44 mm)
3'9" (1,140 mm)
1¾" (44 mm)
3'9" (1,140 mm)
Weight** (including internal components
and filtering medium)
1,210 lb
(550 kg)
1,235 lb
(560 kg)
1,650 lb
(4.1 kg)
1,670 lb
(760 kg)
Factory-set dosage volume
---
25 US gal. (95 L)
---
25 US gal. (95 L)
Maximum dosage volume
---
160 US gal. (605 L)
---
160 US gal. (605 L)
Retention volume (between the bottom of
the containment tank and the bottom of
the filtering medium)
---
255 US gal. (965 L)
---
255 US gal. (965 L)
