SET THERMOSTAT TYPE
1
1
CONFIGURATION
ADJUST HI AND LO LIMIT
FOR PROTECTION, THE EQUIPMENT WILL NOT RUN ABOVE OR BELOW LIMITS. SEE EQUIPMENT STAGING FOR DETAILS.
ON HEAT PUMP EQUIPMENT ONLY, EITHER GAS/ELECTRIC OR HEAT PUMP THERMOSTATS CAN BE USED. THE SMARTZONE CONTROLLER
MUST BE SET FOR THE THERMOSTAT TYPE BEING USED OR THE EQUIPMENT WILL NOT OPERATE PROPERLY WITH POTENTIAL RISK OF
DAMAGE. SET THE THERMOSTAT TYPE AS SHOWN BELOW USING THE “STAT TYPE” AND “ARROW” BUTTONS.
NOTE:
WHEN GAS/ELECTRIC EQUIPMENT, THIS OPTION IS NOT AVAILABLE, ALL THERMOSTATS WILL BE GAS/ELECTRIC.
NOTE 2:
WHEN
USING SMARTLINK FOR 5+ ZONE SYSTEM, SECONDARY CONTROLLER STAT TYPE MUST ALSO BE SET USING THE SAME METHOD.
SET HIGH TEMP LIMIT (CUT-OUT)
SET LOW TEMP LIMIT (CUT-OUT)
NOTE: CHANGING EITHER THE LOW OR HIGH TEMP LIMIT WILL ALSO AFFECT THE STAGING CUT-IN AND CUT-OUT TEMPERATURES
SETTINGS. ADJUSTING THESE CAN CAUSE STAGING TO OCCUR SOONER OR LATER . SEE EQUIPMENT STAGING FOR MORE DETAILS.
SET AUX. HEAT LIMIT (CUT-IN)
SET ECONOMIZER MODE LIMIT (CUT-OUT)
DISPLAY
8E
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
MULTI-FUNCTION DIGITS SHOW SUPPLY TEMPERATURE, CUT-OUT TEMPERATURES
(HIGH AND LOW), ZONE THERMOSTAT TYPES, FRESH-AIR TIME.
DELAY
SMARTZONE CONTROLLER HAS SATISFIED ALL
CALLS AND WILL DELAY 3 MIN BEFORE INITIATING
ANY ADDITIONAL CALLS, COUNTDOWN TIMER ON
DIGITS SEC. IF CALL MADE.
I80
PURGE
SYSTEM IS IN PURGE MODE FOR EQUIPMENT
CHANGEOVER (FAN [G] AND DAMPERS CONTINUE TO
OPERATE, COUNTDOWN TIMER ON DIGITS SEC.)
I80
SETTING HIGH TEMP LIMIT – PRESS UP OR DOWN
ARROW BUTTONS TO ADJUST THE HIGH TEMP LIMIT
(FACTORY DEFAULT: HEAT PUMP – 120
O
F; ELECTRIC
HEAT – 135
O
F; GAS HEAT – 135
O
F)
HI TEMP
HIGH TEMP LIMIT SENSED, SMARTZONE CONTROLLER
DE-ENERGIZES EQUIPMENT HEAT OUTPUT FOR A
MINIMUM OF 3 MINUTES (FAN [G] AND DAMPER
OUTPUTS CONTINUES TO OPERATE)
(FLASH)(ON)
LO TEMP
LOW TEMP LIMIT SENSED, SMARTZONE
CONTROLLER DE-ENERGIZES EQUIPMENT COOL
OUTPUT FOR A MINIMUM OF 3 MINUTES (FAN [G]
AND DAMPER OUTPUTS CONTINUE TO OPERATE)
SETTING LOW TEMP LIMIT – PRESS THE UP OR
DOWN ARROW BUTTONS TO ADJUST THE LOW
TEMP LIMIT (FACTORY DEFAULT 48
O
F)
(FLASH)(ON)
SUPPLY
SUPPLY AIR TEMPERATURE
DISPLAYED NORMALLY
“--“ = SAS DISCONNECTED
IF ZONE 4 HAS BEEN CONFIGURED FOR FRESH AIR AND
FRESH AIR IS BEING CURRENTLY SATISFIED. FAN
SHOULD BE RUNNING AND ZONE 4 (FA DAMPER)
ENERGIZED IN THE OPEN POSITION
ECO
EC INPUT ON ZONE 1 IS ENERGIZED AND SYSTEM IS IN
ECONOMY MODE. ONLY ZONE 1 CAN INITIATE
EQUIPMENT CALLS, OTHER ZONES WILL ONLY OPEN AND
CLOSE DAMPERS AS NEEDED.
(FLASH)(ON)
SE
= SETTING CHANGES STORED IN MEMORY,
THIS WILL SHOW UP AFTER ADJUSTING
ANY SETTING INCLUDING STAT TYPE, LIMIT
TEMPERATURES, AND FRESH AIR TIME.
PRESS THE STAT
TYPE BUTTON...
PRESS THE UP AND
DOWN ARROWS
IF FA IS SELECTED, ZONE 4
DAMPER WILL OPERATE AS A
FRESH AIR DAMPER.
SEE FRESH AIR FOR DETAILS
ZONE:
I
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
H2 AND G2 ONLY ON ZONE 1 ALLOW
THERMOSTAT TO CONTROL STAGING.
SEE ZONE 1 STAGING FOR DETAILS
OPERATION
HOLD
HOLD
9
GE
= GAS / ELECTRIC
HP
= HEAT PUMP
G2
= 2 STAGE GAS/ELECTRIC
H2
= 2 STAGE HEAT PUMP
4
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
ZONE:
PRESS & RELEASE THE ▲ ”UP” ARROW BUTTON WHEN THE DISPLAY IS SHOWING SUPPLY TEMPERATURE.
THE “HI TEMP” INDICATOR WILL FLASH AND THE DIGITS WILL SHOW THE CURRENTLY SET TEMPERATURE. THIS HIGH LIMIT CUT-OUT CAN BE
ADJUSTED UP OR DOWN USING THE ▲▼BUTTONS. SEE EQUIPMENT STAGING BELOW FOR MORE DETAILS.
PRESS & RELEASE THE ▼ ”DOWN” ARROW BUTTON WHEN THE DISPLAY IS SHOWING SUPPLY TEMPERATURE.
THE “LO TEMP” INDICATOR WILL FLASH AND THE DIGITS WILL SHOW THE CURRENTLY SET TEMPERATURE. THIS LOW LIMIT
CUT-OUT CAN BE ADJUSTED UP OR DOWN USING THE ▲▼BUTTONS. SEE EQUIPMENT STAGING BELOW FOR MORE DETAILS.
I35
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
48
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
90
HI TEMP
LO TEMP
SUPPLY
PURGEDELAYECO
PRESS & HOLD THE ▲ ”UP” ARROW BUTTON FOR 5 SECONDS WHEN THE DISPLAY IS SHOWING SUPPLY
TEMPERATURE. WHEN RELEASED THE “HI LIMIT” AND “DELAY” INDICATORS WILL FLASH AND THE DIGITS WILL
SHOW THE CURRENTLY SET TEMPERATURE (DEFAULT = 90, ADJUSTABLE FROM 90 TO 94 USING ▲▼BUTTONS)
OR
GE
FA
= FRESH AIR
GE HP
OR
PRESS & HOLD THE ▼ ”DOWN” ARROW BUTTON FOR 5 SECONDS WHEN THE DISPLAY IS SHOWING SUPPLY
TEMPERATURE. WHEN RELEASED THE “HI LIMIT” AND “ECO” INDICATORS WILL FLASH AND THE DIGITS WILL
SHOW THE CURRENTLY SET TEMPERATURE (DEFAULT = 60, ADJUSTABLE FROM 58 TO 68 USING ▲▼BUTTONS)
ZONES:
2
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
3
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
GE HP
60
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
ADJUST
SETTINGS
STAT
TYPE
GE
PURGECO
OR
WARNING:
USING THIS FEATURE
REDUCES THE
EFFECTIVENESS OF
SMARTZONE'S ENERGY
SAVING STAGING
CONTROLS AND MAY
INCREASE ENERGY USAGE.
WITH ZONE 1 “STAT TYPE” SET TO G2 OR H2, DIP # 4
· OFF (DEFAULT) – SMARTZONE’S ONBOARD STAGING CONTROL [TIME&TEMP]
WILL CONTINUE TO OPERATE 2
ND
STAGE. ZONE 1 STAT WILL BE ABLE TO
ENERGIZE 2
ND
STAGE EARLY BUT WILL NOT PREVENT 2
ND
STAGE FROM
OCCURRING.
· ON (LOCKOUT) – SMARTZONE’S ONBOARD STAGING CONTROL DISABLED AND
ZONE 1 THERMOSTAT WILL BE ABLE TO CONTROL STAGING. (THIS INCLUDES
AUXILIARY HEAT FOR HEAT PUMP)
ZONE 1 STAGING CONTROL ALLOWS A MULTI-STAGE THERMOSTAT CONNECTED
TO ZONE 1 TO CONTROL UP TO 2 COOL AND 3 HEAT STAGES. G2 (GAS/ELECTRIC)
OR H2 (HEAT PUMP) THERMOSTAT TYPE CAN BE SELECTED IN HEAT PUMP MODE.
NOTE: SMARTZONE WILL DELAY 60 SECONDS BETWEEN 1
ST
STAGE START AND 2
ND
STAGE
START. ALSO, A 3 MINUTE MINIMUM OFF TIME IS IMPLEMENTED FOR ALL EQUIPMENT
CALLS. STAGING FROM ZONE 1 THERMOSTAT WILL NOT OVER-RIDE THESE TIME DELAYS.
NOTE 2: WHEN ZONE 1 STAT TYPE IS SET TO G2 OR H2, “ECO MODE” IS DISABLED. TO
ENABLE ECO MODE, SET ZONE 1 STAT TYPE TO GE OR HP.
ZONE 1 STAGING
G2
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
ZONE
1
STAT
R
EC
Y
G
O/B
W
C
C
R
Y1
W2
G
W1
Y2
GAS/ELECTRIC
MULTI-STAGE
THERMOSTAT
R
EC
Y
G
O/B
W
C
ZONE
1
STAT
C
R
Y1
Y2
G
(Aux/EH)
O/B
HEAT PUMP
MULTI-STAGE
THERMOSTAT
H2
HI TEMP
LO TEMP
SUPPLY
PURGEDELAY ECO
10
To Next Page
