Ecolink TLT-ZWAVE2.5 User Manual

© 2015 Ecolink Intelligent Technology Inc. PN TLT-ZWAVE2.5 R1.03
SENSOR
CONDITION
COMMAND CLASS and VALUE
ASSOCIATION GROUP
CONFIGURABLE?
Door Open
Notification Report of Access Control
(0x06), Door is open (0x16)
1
Yes via Notification Set of notificationType
(0x06) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Sensor Binary Report of 0xFF
Sensor Type: 0xFF
1
Yes via Configuration
Command Class Parameter Number: 2
Size: 1
A Configuration Value: 0xFF (On) / 0x00
(Off)
Basic set of 0xFF (On)
2
No
Door Close
Notification Report of Access Control
(0x06), Door is closed (0x17)
1
Yes via Notification Set of notificationType
(0x06) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Sensor Binary Report of 0x00
Sensor Type: 0xFF
1
Yes via Configuration Command Class
Parameter Number: 2
Size: 1
A Configuration Value: 0xFF (On) / 0x00
(Off)
Basic Set of 0x00 (Off)
By factory default this feature is disabled
and must be enabled via Configuration
Command Class.
2
Yes via Configuration Command Class
Parameter Number: 1
Size: 1
A Configuration Value: 0xFF (On) / 0x00
(Off) Parameter Number: 2
Sensor Case Removed
Notification Report of Home Security
(0x07), Tampering product cover
removed (0x03)
1
Yes via Notification Set of notificationType
(0x07) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Sensor Case Fastened
Wake-Up Notification
1
Yes via Wake-Up Notification Command
Class
Battery Level Dipped Below 2.6v
Notification Report of Power
Management (0x08), Replace battery
now (0x0B)
1
Yes via Notification Set of notificationType
(0x08) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
