© 2018 Ecolink Intelligent Technology Inc. PN: H214104 RevA
STEP THREE Mount the Probe:
Mount the probe to a clean dry surface where water is most likley to pool if a leak occurs.
ADDITIONAL NOTES AND SUMMARY:
x The sensor can slide onto the mounting bracket in two different ways. To ensure that the sensor is securely fastened it is recommended that the tab on the
bracket engage the back of the sensor.
x Before attaching the bracket to a surface note how the bracket will need to be oriented in order for the tab to engage the sensor. The required orientation
of the sensor determines the bracket orientation.
x The sensor slides onto the bracket until the tab engages. Please be advised that adhesive tape may damage the surfaces to which it is attached.
