5. Electrical Data
Power Supply: Rechargeable Li-Ion Battery
Nominal Capacity: 2200 mAh
Nominal Voltage: 3.7 V
Maximum Voltage: 4.2 V
Wireless Radio: WLAN: 18 dBm = 63 mW | BT: 11.7 dBm = 15 mW
USB-Interface: Um = 6 V
type of protection intrinsic safety Ex ib IIC
maximum values:
Uo = 4.2 V
Io = 3.75 A
linear characteristic
or Ex ib IIIC
Uo = 4.2 V
Io = 170 mA
Po = 646 mW
6. Approved accessories
The Cube 800 can be used with an approved mechanical accessory, which can
be connected and disconnected directly inside the Ex-area. The hard hat and
climbing helmet mount accessories are marked with an “EX” label to enable
identication.
The following accessories have been approved for use with the device:
• Hard hat mount, EX
• Climbing helmet mount, EX
• Monopod
The monopod must be removed from its woven polyester sleeve before entering
the EX-area.
The maximum length of the monopod is 1 x , 3 x  and 1 x , see Figure 1.
Figure 1



