EcoSmarte Pool System - Installation and System Components; Electrode Chamber Installation and Precautions; Chlorine Level Precaution

The Electrode Chamber may be installed either horizon-
tally or vertically with our Quick Change Unions. Install
the Electrode Chamber between the pump and filter or
between the filter and pool on the pressure side of your
piping. The ECOsmarte Electronic Box can be installed
indoors or outdoors. The Electronic Box is water resistant
and comes with pre-wired leads to be connected to the
Electrode Chamber. If installation requires additional wire,
you may order it from your local ECOsmarte dealer.
CONTENTS OF THIS MANUAL
P. 3 Introduction
P. 5 Start-Up Procedures
P. 7 Water Vocabulary and
Testing
P.13 Closing Your Pool
P.15 Maintenance
P.16-18 Installation
P.19-22 Problem Solving/Guide
P. 22-23 Compatible/Incompatible
P. 24-25 Glass Pack ® Filter Media
P. 33 Free Electrodes for referral
P. 34 Warranty Info: Fax, Scan, Mail
SALTWATER and BROMINE POOLS
must be drained and refilled
Copyright 2004, 2005, 2006, 2007, 2011 Ecosmarte Planet Friendly, Inc. - Richfield, MN
Automated
Systems
DO NOT LET YOUR CHLORINE LEVEL
fall to ZERO prior to install.
TO POOL
WIRE HOOK-UPS
BLACK/WHITE
RED/GREEN
Connect both
to front side
of chamber.
