Introducing the Motherboard

Table of Motherboard Components

LABEL COMPONENTS

Socket AM2+ for AMD Phenom

/Athlon

64X2 Dual-Core/

Athlon

64/Sem

ron

rocessors

2. CPU_FAN

CPU cooling fan connector

3. DRR2_1~4

240-pin DDR2 SDRAM slots

4. ATX_POWE

Standard 24-pin ATX power connector

5. FDD

240-pin DDR2 SDRAM slots

6. IDE

Primary IDE connector

7. SPK

Speaker header

8. CLR_CMOS

Clear CMOS jumper

9. SATA1~5

Serial ATA connectors

10. USB_PWR2

USB Power Select Jumper

11. F_PANEL

Front panel switch/LED header

12. F_USB1~3

Front Panel USB headers

13. COM

Onboard Serial port header

14. SPDIFO

SPDIF out header

15. CD_IN

Analog audio input header

16. F_AUDIO

Front panel audio header

17. PCI1~3

32-bit add-on card slots

18. PCIEX16

PCI Express x16 slot for graphics interface

19. PCIE1~2

PCI Express x1 slots

20. SYS_FAN

System cooling fan connector

21. USB_PWR3

USB Power Select Jumper

22. USB_PWR1

USB Power Select Jumper

23. ATX12V1

4-pin +12V power connecto

1. CPU Socket

This concludes Chapter 1. The next chapter explains how to install the motherboard.

Other manuals for ECS A780GM-A

Manual70 pages

Questions and Answers:

Need help?

Do you have a question about the ECS A780GM-A and is the answer not in the manual?

ECS A780GM-A Specifications

General

Internal memory	32 GB
Number of memory slots	4
Processor socket	Socket AM2
Processor manufacturer	AMD
Compatible processor series	AMD Sempron
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of COM connectors	1
Number of SATA connectors	5
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Motherboard chipset	AMD 780G
Motherboard form factor	ATX
BIOS type	AMI
PCI Express x1 slots	2
Maximum graphics card memory	1920 MB
Controller interface type	AMD SB700
RAID levels	0, 1
