Using BIOS
CPU SMART FAN Control (Enabled)
This item allows you to enable or disable the control of the CPU fan speed by
changing the fan voltage.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
SMART Fan Mode Normal
High Limit Temperature.(°C) 60
Low Limit Temperature.(°C) 37
High Limit PWM 200
Low Limit PWM 56
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9:Optimized Default
F1:General Help
: Move
mnlk
Options
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quite mode, the fan
speed will be auto minimized for quiet environment. If you choose Silent mode, the
fan speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature & CPU Tcontrol, CPU & DIMM voltage, CPU &
system fan speed,...etc.
• CPU Tcontrol
• CPU FAN Speed
• CPU Vcore
• VDIMM
Press <Esc> to return to the main menu setting page.
Shutdown Temperature (Disabled)
Enable you to set the maximum temperature the system can reach before powering
down
Case Open Warning (Disabled)
This item enables or disables the warning if the case is opened up, and the item below
indicates the current status of the case.
Chassis Opened (No)
This item indicates whether the case has been opened.
