ECS A785GM-M5 User Manual

6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom
TM
II/Phenom
TM
processor (socket AM2+)/AMD
Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/Sempron
TM
processors
2. CPU_FAN CPU cooling fan connector
3. DDR2_1~2 240-pin DDR2 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. IDE Primary IDE connector
6. SATA1~6 Serial ATA connectors
7. CLR_CMOS Clear CMOS jumper
8. F_PANEL Front panel switch/LED header
9. SYS_FAN System cooling fan connector
10. SPK Speaker header
11. LPT Onboard parallel port header
12. USBPWR_F Front Panel USB power select jumper
13. F_USB1~2 Front Panel USB headers
14. SPDIFO SPDIF out header
15. CD_IN Analog audio input connector
16. F_AUDIO Front Panel Audio header
17. PCI1~2 32-bit add-on card slots
18. CASEOPEN Chassis detect header
19. PCIE1 PCI Express x1 slot
20. PCIEX16 PCI Express x16 graphics card slot
21. USBPWR_R Rear Panel USB PS/2 power select jumper
22. ATX12V 4-pin +12V power connector

ECS A785GM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Graphics card	Radeon HD 4200
Maximum graphics card memory	512 MB
RAID levels	0, 1, 10

Weight and Dimensions

Depth	210 mm
Width	244 mm
