ECS A785GM-M5 User Manual

13
Installing the Motherboard
Table A: Unbuffered DIMM Support for Socket AM2+/AM2 CPU
The default value is unganged mode when using socket AM2+ CPU.
DRAM Speed DIMM1
1
DIMM2
1
Timing Mode
DDR2-400 - Any 1T
DDR2-400 Any Any 2T
DDR2-533 - Any 1T
SRx16 SRx16
SRx16 SRx8 DDR2-533
SRx8 SRx16
2T
DDR2-533 SRx8 SRx8 2T
DDR2-533 DRx8 DRx8 2T
DRx8 SRx16
DDR2-533
SRx16 DRx8
2T
DRx8 SRx8
DDR2-533
SRx8 DRx8
2T
DDR2-667 - Any 1T
SRx16 SRx16
SRx16 SRx8 DDR2-667
SRx8 SRx16
2T
DDR2-667 SRx8 SRx8 2T
DDR2-667 DRx8 DRx8 2T
DRx8 SRx16
DDR2-667
SRx16 DRx8
2T
DRx8 SRx8
DDR2-667
SRx8 DRx8
2T
DDR2-800 - Any 2T
DDR2-800 Any Any 2T
1. SRx16=Single Rank x16 DIMM
SRx8=Single Rank x8 DIMM
DRx16=Dual Rank x16 DIMM
DRx8=Dual Rank x8 DIMM

ECS A785GM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Graphics card	Radeon HD 4200
Maximum graphics card memory	512 MB
RAID levels	0, 1, 10

Weight and Dimensions

Depth	210 mm
Width	244 mm
