ECS A785GM-M5 User Manual

15
Installing the Motherboard
Due to the Phenom CPU and memory module limitation, the DRAM may
need to adjust the voltage for supporting DDR2 1066. The memory mod-
ules which can be used stably are listed in the above QVL table for refer-
ence.
Type Size Vendor Module Name
A-DATA Red A-DATA M2OMI6H3J4720L1C5Z
78.A1GAO.9K4
Apacer
78.A1GC0.9L4
CORSAIR CM2X2048-6400C5
Geil Geil Platinum Edition
Hynix HYMP125U64CP8-S6 AB
KingMax KLDE88F-B8KU5 NHES
KVR800D2N5/2G
Kingston
KVR800D2N6/2G-SP
Micron MT16HTF25664AY-800E1
Nanya NT2GT64U8HD0BY-AD
PSC AL8E8F73C-8E1
M378T5663QZ3-CF7
Samsung
M378T5663EH3-CF7
Silicon
Power
SP002GBLRU800S01
2 GB
Unifosa GU342G0ALEPR692C6CE
Kingston KVR800D2N6/4G
DDR2 800
4 GB
Samsung M378T5263AZ3-CF7 0819
Infinity 04701G16CY5U2A
Micron MT8HTF12864AY-1GAE1
1 GB
OCZ OCZ2RPR 10662GK
DDR2 1066
2 GB
Micron MT16HTF25664AY-1GAE1

ECS A785GM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Graphics card	Radeon HD 4200
Maximum graphics card memory	512 MB
RAID levels	0, 1, 10

Weight and Dimensions

Depth	210 mm
Width	244 mm
