ECS A785GM-M5 User Manual

Setting Up eJIFFY
64
2. Then the “Save Image” window appears. You may rename the image file in the
“Name” column and save the file in a folder as the following picture shows.
1. Select the image you want to save and press the right key of your mouse to show
the menu, then click the option “ Save Image As” from the menu.
Q3: How to save image file through eWeb?
Select a root
directory.
Rename the image file.
Then select a
subdirectory
or click
“Create
Folder” to
create a new
folder.
Click here to
save the image
file.

ECS A785GM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Graphics card	Radeon HD 4200
Maximum graphics card memory	512 MB
RAID levels	0, 1, 10

Weight and Dimensions

Depth	210 mm
Width	244 mm
